Electric Industrial Goods Lift
2000 kg Goods Lift
An electric goods lift that features
- MRL Machine Room-less
- Three-phase Gear Motor with frequency variations
- Quiet Operation
- Stability & Reliability
This industrial goods lift is available with a duty load from 500kg – 2000kg. Suitable for both goods and passengers.
The goods lift can achieve a lift travel of up to 20 meters and only requires a minimum pit of 120mm
You can select from three options for the landing doors, which include light curtains
- Swing Door
- Automatic Door
- Folding Shutter gates
Lift Finishes
The lift walls, ceiling, bumpers and front panels are available in stainless steel or painted sheet metal.
Lift floors offer a choice of checker plate or non-slip stainless steel.
LED Lighting panel.
| BASIC TECHNICAL INFORMATION | |
|---|---|
| STANDARDS | EC Machinery Directive 2006/42/CE |
| MAX DUTY LOAD (Kg) | 500 – 1000 – 1500 - 2000 |
| RATED SPEED (m/s) | 0.15 |
| STARTS PER HOUR | 20 |
| MAX LIFT TRAVEL (M) | 20 |
| MIN PIT (mm) | 120 |
| MIN HEADROOM (mm) | 2400 |
| POWER SUPPLY (TNP) | 400V / 3 Phase / 50 Kw |
| DRIVE SYSTEM | GEARED TRACTION |
| ENTRANCE OPTIONS | SINGLE ENTRANCE | THROUGH ENTRANCE |
| MIN SHAFT WIDTH (mm | 1700 |
| MIN SHAFT DEPTH (mm) | 1500 |
