iKONIC FIRE LIFTS
FIREFIGHTER LIFT Cert to BS EN 81-72
Our firefighter lifts are supplied and installed in accordance with BS EN 81-72. We advertise two of our most popular models, which have different load capacities to meet today’s requirements. Our lifts are perfect for application in new developments or existing buildings, and we have many proven solutions for low headroom and pit depths. The lifts are handed over as fully verified passenger lifts, fully accredited to BS EN 81-72.
iKONIC Fire Lift
This lift accommodates most requests for firefighter lifts. With a load capacity of 1000kg, it allows for up to 13 people to use the lift, and it functions as a regular passenger lift when not required by the fire service. Suitable for both commercial and residential properties. Featuring a rated speed of 1.0m/s and is able to cover travel of up to 45 metres. The iKONIC Fire also offers the option to have entrances on 3 different sides of the lift car.
iKONIC Fire Heavy Duty
As the name Heavy Duty suggests, this lift can handle greater load capacities and travels faster between floors than the iKONIC Fire. This firefighter lift has a maximum load capacity of 8000kg and can travel up to 50 metres at a speed of 1.6 metres per second.
| iKONIC FIRE BASIC TECHNICAL INFORMATION | |
|---|---|
| STANDARDS | BS EN 81-20/50 BS EN 81-21 BS EN 81-28 BS EN 81-70 BS EN 81-71 BS EN 81-72 |
| MAX DUTY LOAD (Kg) | 1000 - 8000 |
| RATED SPEED (m/s) | 1.6 |
| STARTS PER HOUR | 240 |
| MAX LIFT TRAVEL (M) | 50 |
| PIT (mm) | 1200 |
| HEADROOM (mm) | 3400 |
| POWER SUPPLY (TNP) | 400 V 3 Phase 50 Hertzs |
| DRIVE SYSTEM | Geared Traction |
| ENTRANCE OPTIONS | Up to 1000Kg ADJACENT, THROUGH ENTRANCE |
