iKONIC Heavy Duty Mars
10000kg Goods and Passenger Lift
iKONIC Mars Gearless Traction Lift is suitable for use in multi-applications where frequent footfall is expected. It is ideal for use in hotels and educational facilities, as well as when you require a dual lift for goods and passengers.
For companies working on a budget but still demanding quality, performance, and safety, the iKONIC MARS lift is an excellent standard option. Providing a higher-than-average capability and is an excellent choice for heavy-duty commercial applications.
It can be modified or upgraded as needed to meet your requirements. There is no need for a machine room, allowing for greater design flexibility, and it can be adapted to an infinite number of pre-existing lift shafts.
iKONIC Mars Goods Plus Passenger Lift comes in various shapes and sizes with open protocol technology
There are a huge variety of finishes and optional extras available.
This iKONIC Heavy Duty MARS Goods Lift offers a load capacity of a staggering 10,000kg. Suitable for commercial applications. It boasts a top speed of 1.6 m/s and can cover a distance of up to 45 meters.
Advantages
- Suitable for reduced pit depth and headroom
- Suitable for existing shafts
- Adaptable to an infinite number of shafts
- Customise to your heart’s content
- Offers a wide range of load sizes and speeds
- Resistant and reliable performance
- MINIMAL acoustic levels
- Long life and minimal maintenance
| HD MARS BASIC TECHNICAL INFORMATION | |
|---|---|
| STANDARDS | BS EN 81-20/50, BS EN 81-70, BS EN 81-71, BS EN 81-73 |
| MAX PERSON CAPACITY | Multiple Attendants |
| MAX DUTY LOAD (Kg) | 10000 |
| RATED SPEED (m/s) | <1.6 |
| STARTS PER HOUR | 240 |
| MAX LIFT TRAVEL (M) | 45 |
| PIT (mm) | 1200 |
| HEADROOM (mm) | 3400 |
| POWER SUPPLY (TNP) | Single and Three Phase dependant on size |
| DRIVE SYSTEM | MRL |
| ENTRANCE OPTIONS | SINGLE ENTRANCE, THROUGH ENTRANCE |
